Availability: | |
---|---|
Quantity: | |
1. MOQ: 1 Tons
2. Trade Terms: EXW, FOB, CIF, CNF, DDU, DDP, etc
3. Standard: GB, ASTM, JIS, AISI, DIN, BS.
4. Shipping: BY SEA
5. After-sales Service: Quality Objection Within 10 Days Since Receiving
6. Shape: square type
Product description
Material Standard | Q235B, A36,SS400, Q355B, Q355C, Q355D, Q355E, S235JR, S235J0, S235J2,S275JR, S275J0, S275J2, S355JR, S355J0, S355JR |
Size(mm) | 16*16-250*250 mm 10*20-120*80mm |
Technique: | Hot dip Galvanized, Pre-galvanized, Color Painting, Coated, Cutting, Punching as long as you can tell us your requirement. |
Section: | Square type |
Surface treatment | untreated(black), hot-dipped galvanized ,powder coated, electroplate, painting or as per customers' requirement. |
Test: | SGS,BV and so on |
Packing | (1) LCL(less than one container load): packed with plastic film then on the pallets (2) FCL(full container load): nude packing (3) Other special package :according to customers' requirements. |
Payment Term | 1.100% irrevocable L/C at sight. 2.30% T/T prepaid and the balance against the copy of B/L. 3.30% T/T prepaid and the balance against L/C |
SHS/RHS Size Sizes
Out Diameter | Wall Thickness | Square Pipe/Tube(mm) | Rectangular Pipe/Tube(mm) | |||
Inch | mm | mm | 16×16×0.4~1.5 | 70×70×2.0~6.0 | 10×20×0.6~1.5 | 30×60×1.0~4.5 |
1/2 | 21.3 | 0.6-3.0 | 18×18×0.4~1.5 | 75×75×2.0~6.0 | 14×21×0.6~1.5 | 40×50×1.0~4.5 |
3/4 | 26.9 | 0.6-3.0 | 20×20×0.4~1.5 | 80×80×2.0~6.0 | 15×30×1.5~1.5 | 40×60×1.0~5.0 |
1 | 33.4 | 1.0-3.0 | 25×25×0.6~2.0 | 85×85×2.0~6.0 | 15×38×0.6~1.5 | 40×80×1.5~5.0 |
1 1/4 | 42.3 | 1.0-4.0 | 30×30×0.6~4.0 | 95×95×2.0~8.0 | 20×30×0.6~2.0 | 40×100×2.0~5.0 |
1 1/2 | 48.3 | 1.0-4.0 | 34×34×1.0~2.0 | 100×100×2.0~8.0 | 20×40×0.8~2.0 | 50×60×2.0~5.0 |
2 | 60.3 | 1.5-4.0 | 35×35×1.0~4.0 | 120×120×4.0~8.0 | 20×50×1.0~2.0 | 50×80×2.0~5.0 |
2 1/2 | 76.1 | 1.5-4.0 | 38×38×1.0~4.0 | 150×150×6.0~10.0 | 22×35×0.9~2.0 | 50×100×2.0~8.0 |
3 | 88.9 | 1.5-9.5 | 40×40×1.0~4.5 | 180×180×6.0~12.0 | 25×40×0.9~3.75 | 60×80×2.0~6.0 |
4 | 114.3 | 2.0-9.5 | 44×44×1.0~4.5 | 200×200×6.0~12.0 | 25×65×1.0~2.0 | 80×100×2.0~8.0 |
5 | 141.3 | 3.0-9.5 | 45×45×1.0~5.0 | 220×220×6.0~14.0 | 30×40×1.0~3.75 | 120×60×2.5~10.0 |
6 | 168.3 | 3.0-12.0 | 50×50×1.0~5.0 | 250×250×6.0~14.0 | 30×45×1.0~3.75 | 120×80×2.5~10.0 |
8 | 219.1 | 3.2-12.0 | 60×60×1.5~5.0 | 30×50×1.0~4.0 | ||
10 | 273 | 3.2-12.0 | ||||
12 | 323.8 | 6.0-15.0 | ||||
14 | 355.6 | 8.0-15.0 | ||||
16 | 406.4 | 8.0-20.0 |
Packing & Delivery
Packing | 1.By steel strips in bundles |
2.By woven cloth with 7 slats | |
3.By woodenn pallet | |
4.Accorging to the requirements of customers |
Delivery | By sea | 1.In bulk ( based on 200tons) |
2.20ft container: 25tons (Length limted 5.8m MAX) | ||
3.40ft container:(Length limted 11.8m MAX) | ||
By air | UPS/DHL/FEDEX | |
By truck | as customer ruquests |
